Product Description
Product Introduction
the outer spherical ball bearing is actually a variant of the deep groove ball bearing, characterized by its outer ring outer diameter surface being spherical, which can be matched into the corresponding concave spherical surface of the bearing seat to play a centering role.
Technical Specifications
| Demesions: | |
| Bearing No. | 6004, 6004-ZZ, 6004-2RS, 6004Z, 6004RS, 6004 ZZ, 6004 RS |
| Bore diameter (d) | 20 mm |
| Outer diameter (D) | 42 mm |
| Width (B) | 12 mm |
| Basic Load Rating(N) | |
| Dynamic(Cr) | 9400 |
| Static(Cor) | 5050 |
| Max. Speed(RPM) | |
| Grease | 17000 |
| Oil | 21000 |
| Weight(g) | |
| Approx. | 69 |
| Grade | P0, P6, P5 |
| Radial Clearance | C0, C2, C3 |
